When there's no room for a new 240V circuit, the Smart Splitter lets the EV charger share the dryer circuit. Quote a Level 2 install the homeowner says yes to — not a service upgrade they sit on.
Avg. saved vs. a panel upgrade$2,200stays in the homeowner’s budget
Why pros carry it
The job you used to lose is now a same-day install.
Most panel-upgrade quotes stall. A Splitter quote closes, because it fits the budget the homeowner walked in with.
Full panels
Close the full-panel quote.
No breaker space or capacity for a new 50A circuit? Share the existing dryer circuit and keep the job.
No new circuit or service upgrade
Dryer gets priority, automatically
Both loads never run at once
Fast install
Plug in, mount, done.
The Splitter plugs into the existing receptacle and the charger plugs into the Splitter. Under 10 minutes for the Splitter itself.
No hardwiring for the Splitter
Pairs with plug-in Level 2 chargers
Autel, Wallbox, LENZ and EVIQO bundles
Code & safety
Listed, and built to manage load.
Safety certified for the US and Canada and on utility eligible-device lists — one circuit, never overloaded.
cUL listed (US & Canada)
On PG&E, SMUD and BC Hydro approved lists
3-year warranty with the Pro Package
Fewer callbacks
The app answers the calls you’d get.
Homeowners see every charge, its cost and the schedule in the NeoCharge app. Wi-Fi updates and remote troubleshooting are built in.
Over-the-air firmware updates
Remote troubleshooting
Off-peak scheduling set at handover
Jobs you’ll see this month
Four jobs that used to need a new circuit.
Real homeowners, real quotes. Every one kept the panel it had.
Dryer + one EV
The Splitter gives the dryer priority and hands power back when it's done.
★★★★★
Saved me from spending $2,100 on an additional 240V/30A circuit. Cut my Mach-E charging time from 24 hours to 6. Auto-switches with the dryer.Saved me from spending $2,100 on an additional 240V/30A circuit.
CraigFord Mach-E owner
Two EVs, one outlet
Charges one, then the other overnight. Or both at once at half power.
★★★★★
My wife and I both plug in. When her car finishes charging in the middle of the night, it switches to mine automatically. No second outlet, no second circuit.My wife and I both plug in.
Scott E.Two-EV household
A panel that's already full
No new circuit, so no panel upgrade and no permit.
★★★★★
My panel couldn't handle another 240V circuit. No permits, no $15k panel upgrade — sheer genius. The Smart Splitter shares my dryer outlet.My panel couldn't handle another 240V circuit.
Alex P.Tesla Model 3 owner
Laundry room, car in the garage
A cord run gets you from the outlet you have to where you park.
★★★★★
New Tesla, no new outlet install. Ran a 25-foot cord from the laundry room ceiling out to the garage. Defaults to the dryer so my wife doesn't have to think about it.New Tesla, no new outlet install.
Peter M.Tesla owner
Swipe for more →
Two products, every full panel
Two ways to say yes to a full panel.
Plug-in when there's a dryer outlet to share. Panel-installed when the home needs a new charger circuit and the service is tight.
Plug-in · No new circuit
Smart Splitter
Shares the existing dryer or 240V circuit with the EV charger. The dryer gets priority, so the circuit never carries both loads.
Sensors on the main service let a new charger circuit run as fast as the panel safely allows, and slow down when the house gets busy. No service upgrade.
200A sensors, Wi-Fi + Ethernet
Works with Smart Splitter and Autel AC Elite (OCPP)
Everything you need to spec it.Two EVs on one 50A circuit.
The 24A model for 30A dryer circuits, the 40A model for 50A circuits. Toggle to see both.Charge two cars from a single 240V receptacle, in turn or at the same time.
Under 10 minutes
Plugs into the existing dryer receptacle. No new circuit, no panel work.Plugs into the existing 240V receptacle. No second circuit.
Charges off-peak
Set a time-of-use schedule in the app. It waits for your cheapest rates.
24 AUp to 40 A
5.7 kW on your 30 A dryer circuit. Up to 5× faster than a wall outlet.9.6 kW of Level 2 on a 50 A circuit. Up to 7× faster than a wall outlet.
Drag to rotate
5.25″ × 5.25″ × 2.8″ 2.5 lbs · Made in USA
Auto-switching
Dryer starts, charging pauses. Dryer stops, charging resumes.First car fills, then power moves to the second. Nothing to unplug.
Cost tracking
Every charge, by car and by month, in the NeoCharge app.
cUL Listed
Safety certified for the US and Canada.
Wi-Fi built in
Over-the-air updates and remote troubleshooting.
20 A + 20 A
Set both EVs to 20 A and they charge at the same time.
10-3014-30
Both dryer outlets
NEMA 10-30 and 14-30, the two standard dryer plugs.
10-3014-3010-5014-506-50
5 outlet types
NEMA 10-30, 14-30, 10-50, 14-50 and 6-50.
1-year warranty
On every unit. Pro Package: 3 years plus 60-day returns.
240 V single-phase, indoor use. 24 A model fits 30 A dryer circuits; 40 A model fits 50 A circuits. Simultaneous charging requires each load set to 20 A or less. 60-day returns with the Pro Package apply to U.S. orders.
On the job
Quote it, install it, hand over the app.
Survey the outlet and panel
Full panel or a long run to the garage? Note the receptacle — 10-30, 14-30 or 14-50 — and pick the matching Splitter.
Install the Splitter and charger
Plug the Splitter into the receptacle, mount it, and plug in the charger.
Under 10 minutes
Hand over the app
Pair the Splitter to the homeowner's Wi-Fi in the NeoCharge app and set an off-peak schedule before you leave.
Rebates that help you close
Show what comes back before they sign.
Utilities pay customers for the Splitter, and some cover the electrical work to install it.
Up to $750
SMUD Contractor NetworkSacramento
Toward a new circuit for a charger or circuit-sharing device — plus $200 off the Splitter.
Up to $600
Tacoma PowerWashington
$400 bill credits for the smart splitter and for the electrical work to install it.
Up to $550
BC HydroBritish Columbia
Charger rebate plus a $200 Splitter top-up. The permit you pull counts toward it.
Up to 100%
PG&ECalifornia
50% of the device price; income-qualified Rebate Plus homes can be fully covered — up to $5,000 with qualifying panel work.
$1,500+
3CE Electrify Your RideCentral Coast, CA
Toward a networked Level 2 charger and its install — smart splitters count as install costs.
$250–$500
Holy Cross EnergyColorado
Plug-sharing device rebate that names the NeoCharge Smart Splitter as the example.
Amounts as of October 2026. Programs change — check each utility’s current terms.
No. It plugs into an existing 240V receptacle and shares that circuit between the appliance and the EV charger. Permit requirements depend on your jurisdiction and the rest of the job — in British Columbia, for example, BC Hydro’s rebate requires an electrical permit.
What is the NeoCharge Energy Monitor?
A whole-home monitor you install inside the panel. Its 200A sensors read the main service, and the charger speeds up or slows down so the home stays within the panel’s rating — no service upgrade. It works with the Smart Splitter and the Autel AC Elite today, and a licensed electrician must install it.
How does it run a dryer and an EV on one circuit?
The dryer gets priority. When it starts, charging pauses; when it stops, charging resumes automatically. The circuit never carries both loads at once.
Which receptacles and amperages are supported?
NEMA 10-30, 14-30, 10-50, 14-50 and 6-50 in the US (14-30 and 14-50 in Canada). The 24A model is for 30A dryer circuits; the 40A model is for 50A circuits. 240V single-phase, indoor use.
Is it listed, and what is the warranty?
It is cUL listed for the US and Canada. Every unit has a 1-year warranty; the Pro Package extends that to 3 years with 60-day returns.
Which chargers can plug into it?
Plug-in Level 2 chargers with a matching NEMA plug. We sell bundles with Autel, Wallbox, LENZ and EVIQO chargers.
